Features
- Intel® Core™ i5-8265U/i7-8565U Processor
- Rugged enclosure and fanless design
- M12 I/O connectors and standard interfaces are reserved on the back
- -30 ~ +70°C Operating Temp.
- 9~36V DC input with ignition control
- Flexible expansion capability for WiFi, Bluetooth, LTE/5G, GPS, CAN2.0B
The MVC series are rugged vehicle computers launched by Darveen for mining and other industries. They are equipped with Intel® J1900 or Core™-i low-power processor and pre-installed Windows operating system. It can fully utilize Microsoft Windows data processing capabilities in mobile vehicles and improve application and network management capabilities while maintaining the flexibility and ease of use of multi-tasking applications.
The MVC series can be extended to 802.11a/b/g/n/ac, Bluetooth V4.0, full Netcom LTE, dedicated network 1.4G/1.8G LTE, GPS/GNSS/Beidou/RTK, CAN2.0B and other modules, 8~36V wide voltage DC input power management with Power ignition delay switch function, in addition, the whole series adopts high-strength and thickened metal shell, which meets the STD-MIL-810G anti-vibration and shock standard, and can still operate freely in the most severe environments.
Datasheet MVC-4246
